Feed Pellet Mill Machine (Pellet Press) SZLH508

  • Model: SZLH508

  • Capacity 4-18t/h Get Price

  • Main motor power: 160kw

  • Conditioner power: 7.5kw

  • Feeder power: 2.2kw

  • Ring die diameter: 508mm

We're here to help:

Easy ways to get the answers you need.

(※ Click this button to inquiry)
Follow Us :
| share: Bookmark and Share
  • Feed Mill Equipment High Performance SZLH508
  • feed mill equipment for sale
  • feed mill equipment
  • feed mill equipment suppliers
  • Feed Pellet Mill Machine
■ Description

High Performance SZLH508 Feed Mill Equipment (Feed Pellet Press)

SZLH series feed pellet machine (pellet press) is America CPM Model machine,High-strength precision gear drive,Transmission efficiency can be as high as 99%,The normal belt transmission efficiency of 90% -95%, and easy to slip loose, life is short, when the belt becomes loose, transmission efficiency will drop a lot, in normal with the same power ,gear drive Pellet machine output should be increased by 20% -30% than the belt drive,can work alone with its electric cabinet.It can used in all kinds of large,middle and small farms (feed pellet production line) to make feed pellet to feeding animals,for raw materials,it can be grain,such as wheat,corn,maize, etc.,and some grass,straw also can be applied to this machine,has a very broad application.

This Feed Pellet Manufacturing Machinery Detailed instructionsfeed pellet machine application
1 For the machine,raw material can be corn,wheat,and other grains,grass also ok.
2 If the raw material are powder,can be make into pellets directly.
3 If the raw material is particle size,first,we need crush them to powder less then 3mm powders. and there also some requests for the raw material moisture,it is better if less than 30%.
4 If you want to make different size pellets,the size,generally we mean the diameter of the pellets,you can buy several different size ring die.

The machine can make pellets for poultry, cow, cattle,pig,chicken and so on.mainly sinking pellets,because the density of the pellets are big, if you want to make floating feed, so you need to buy one more extruder.

Perfect after-sale service

a. After installation and adjust,we will training our customer's work how to operate;
b. Training worker how to maintain and protect;
c.  According features,we will make a complete maintain rules for you, contains how to maintain,when to maintain,who maintain);
d. Our company after-sale department will call you at regular intervals,ask if maintain and give advice.


■ Features

High Performance Feed Mill Equipment (Feed Pellet Press) SZLH508

1.Host bearings generally use the top ten brands in the world of NSK (Japan), SKF (Switzerland) bearings, reliable quality, long service life!
2. In.the rear of pellet machine has the protection switch device , when the spindle bearing and spindle lock, the power can be cut off in time, the spindle has an effective protection effect!
3. Feeder spindle, screw, sleeve, paddle are 304 stainless steel,bearing is SKF brand,longer life.
4. The gap between paddle and the bottom is less than 4mm, the material basically no residue, no manual cleaning residue,but other manufacturers is generally 8-10mm, more material leftovers, If the labor can not be timely clean-up, material cross-contamination, if for a long time production is also easy to pests!
contact Strongwin pellet machine factory 5.Conditioner spindle, paddle, bolt ,wall tube are 304 stainless steel, Conditioner paddle stainless steel castings, bolts fixed installation, angle adjustable, but other factory is welding, the angle can not be adjusted. Conditioner can be adjusted by adjusting the paddle then adjust the material to stay time in conditioner. This is the welding pad can not do!
6.Pellet machine door with 304 stainless steel, other use ordinary carbon steel, pellets from the machine high temperature, moisture, ordinary carbon steel life is generally about six months, and The service life of stainless steel is long-term!
7.Door cutter with a graduated mark can be more accurate regulation of the pellet length, the other manufacturers generally do not have the mark of the cutter!
8.Holder, the ring die, roller high-strength alloy forged pieces, the CNC machining heat treatment, high precision, high strength and long service life!



■ Parameters

High Performance Feed Mill Equipment SZLH508

Model SZLH508
Main motor power 160kw
Conditioner power 7.5kw
Feeder power 2.2kw
Ring die diameter 508mm
Capacity 4-18t/h
Finished pellet size 2-18mm


Contact Strongwin to Get Details and Latest Price contact Strongwin pellet machine factory

 ring die of feed pellet machine
Maybe you willing to know other related ring die pellet machine
Ring Die Feed Pellet Mill SZLH350
Animal Feed Pellet Machine SZLH250
Animal Feed Pellet Press SZLH420
Long Lifetime Feed Pellet Mill SZLH320
Feed Pellet Machine (Pellet Press) SZLH400

You can enquire us to learn more on all type and capacity of feed pellet machiney, of course, we provide expert custom service, so let us know what you want please.
